Model name |
EAR-100T (Preliminary) |
Processor |
NVIDIA Jetson T5000™
Blackwell GPU + Arm Neoverse V3AE CPU |
|
Main Memory |
128 GB (8 x 16 GB) memory with 256-bit LPDDR5X DRAM |
Storage |
1 x M.2 M-Key 2280, support NVMe |
SIM Slot |
1 x Nano SIM Card Socket |
Audio Input |
1 x Mic in (Optional) |
CAN Bus |
2 x CAN-FD |
USB |
4 x USB 3.2, Type-A (Optional) |
Audio Output |
1 x speaker |
Power |
19 ~ 36 VDC
3-pin Terminal Block |
Supported Software |
NVIDIA JetPack™ 7.0 |
Ethernet |
2 x 5 GbE LAN, RJ45 |
Expansion Slot |
1 x M.2 E-key (2230) for Wi-Fi/BT | 1 x M.2 M-key (2280) for NVMe SSD | 1 x M.2 B-key (3052) for 4G/5G |
Dimensions (W x D x H) |
-20 ~ 60 °C (-4 ~ 140 °F) |
Envirement |
Operating Temperature: -20 ~ 60 °C (-4 ~ 140 °F)
10% ~ 95% relative humidity, non-condensing
Storage Temperature: -40 ~ 85 °C (-40 ~ 176 °F) |
Debug Port |
1x Micro USB |
GSML Camera |
12 x FAKRA Z code with frame syn |
Wireless |
1 x M.2 E-Key 2230, Wi-Fi/BT | 1 x M.2 B-Key 3052, 4G/5G |
